A3E_TOF 25-Pin DF36 Shielded Cable Assembly:

25-Pin DF36 Connector Cable Assembly
Equipped with DF36-25P-0.4SD connectors with metal shielding shell, face-up orientation
for stable board-to-board connection.

Controlled Impedance & High Signal Integrity
Designed with flat shield and conductive tape, characteristic impedance 50Ω ±10%, no
discontinuity over ±8Ω (TDR tested).

Ultra-Fine AWG44 Wire Construction
Uses UL1911 AWG44 wires, optimized for compact electronic assemblies requiring
precision and flexibility.

Enhanced EMI Shielding & Reliability
Conductive tape, shield pleat structure, and UV resin reinforcement (≤1 mm) ensure
excellent EMI protection and mechanical durability.

Tested to IPC-WHMA-A-620D Class 2
Fully tested for continuity, insulation resistance (≥50 MΩ @100V), and dielectric strength
(AC120V / 1s).

A3E_TOF 25-Pin DF36 Shielded Cable Assembly Product Description:

This A3E_TOF 25-Pin Shielded Cable Assembly is engineered for high-density electronic
applications requiring stable signal transmission and compact design.

The assembly features Hirose DF36 series 0.4 mm pitch connectors with integrated metal
shielding, combined with AWG44 ultra-fine wires and flat shield construction. Conductive
tape and controlled shield thickness enhance EMI performance while maintaining flexibility.

Each cable is manufactured in compliance with IPC-WHMA-A-620D Class 2 standards and
undergoes full electrical testing, including insulation resistance, dielectric strength, continuity,
and impedance verification.
Ideal for TOF sensors, embedded modules, and compact PCB interconnect applications.

A3E_TOF 25-Pin DF36 Shielded Cable Assembly Specifications:

A3E_TOF 25-Pin DF36 Shielded Cable Assembly Applications:

Time-of-Flight (TOF) sensor modules

Embedded camera & sensing systems

Compact PCB interconnects

Industrial and consumer electronics assemblies
